A Digital Twin Framework for Testing, Evaluation and Deployment of Resilient Cyber-physical Systems

Abstract

As the level of automation in critical infrastructure increases, the ability to detect cyber intrusions becomes more crucial and extremely challenging. Recent cyber attacks demonstrate the devastating and widespread affects they can have on critical infrastructure. We describe an approach to detect and prevent cyber attacks by continuously comparing the infrastructure state with a real-time digital-twin simulation of it. Specifically, we describe and demonstrate a Digital Twin Framework (DTF) designed specifically to detect and eventually prevent such attacks. Our framework and models are validated against experimental data from two critical infrastructure experimental emulators, first for a canal lock system and second, an electric distribution system. These systems are chosen as they have very different dynamics. The canal lock system’s digital twin uses a recurrent neural network trained from the experimental data collected via the DTF. A digital twin of the transmission system is created using a commercial real-time power systems simulator and integrated into our DTF along with the hardware, embedded controllers, and live sensor data using the Open Field Message Bus data model, and publish/subscribe communication protocols. A cyber attack is used on both systems to demonstrate the DTF’s detection capability.
